MCP Server Integration¶

The debug toolbar includes an MCP (Model Context Protocol) server that allows AI assistants like Claude Code to analyze your application’s debug data programmatically.

MCP Integration with Claude Code

Installation¶

Install with MCP support:

uv add debug-toolbar[mcp]
# or
pip install debug-toolbar[mcp]

Quick Start¶

1. Configure Your App with Shared Storage¶

The web app and MCP server need to share a storage file. Update your app:

from litestar import Litestar, get
from debug_toolbar import FileToolbarStorage
from debug_toolbar.litestar import DebugToolbarPlugin, LitestarDebugToolbarConfig

@get("/")
async def index() -> dict:
    return {"message": "Hello"}

# Use file-based storage for sharing with MCP server
storage = FileToolbarStorage(".debug_toolbar_storage.json", max_size=100)

config = LitestarDebugToolbarConfig(
    enabled=True,
    storage=storage,  # Share storage with MCP server
)
app = Litestar(
    route_handlers=[index],
    plugins=[DebugToolbarPlugin(config)],
)

2. Configure Claude Code¶

Add to your ~/.claude/settings.json (global) or .claude/settings.json (project):

{
  "mcpServers": {
    "debug-toolbar": {
      "command": "uv",
      "args": ["run", "python", "-m", "debug_toolbar.mcp", "--storage-file", ".debug_toolbar_storage.json"],
      "cwd": "/path/to/your/project"
    }
  }
}

Important: The cwd must point to where your web app runs (where the storage file is created).

3. Restart Claude Code¶

After updating settings, restart Claude Code to load the MCP server.

4. Generate Request Data¶

Start your web app and make some requests. The storage file will be created and populated.

5. Ask Claude Code to Analyze¶

Once you have requests flowing through your app, ask Claude Code questions like:

“What requests have been made to my application?”
“Are there any slow endpoints?”
“Check for security issues in my app”
“Generate a performance optimization report”
“Are there any N+1 query patterns?”

Available MCP Tools¶

Request Analysis¶

Tool	Description	Example Prompt
`get_request_history`	List recent HTTP requests	“What requests have been made?”
`get_request_details`	Get detailed info for a specific request	“Show me details for request abc123”
`get_panel_data`	Get data from a specific panel	“What does the Timer panel show?”

Performance Analysis¶

Tool	Description	Example Prompt
`analyze_performance_bottlenecks`	Find slow operations	“Are there any slow endpoints?”
`compare_requests`	Compare timing between requests	“Compare the /api and /users endpoints”
`generate_optimization_report`	Full performance report	“Generate a performance report”

Database Analysis¶

Tool	Description	Example Prompt
`detect_n_plus_one_queries`	Find N+1 query patterns	“Are there any N+1 queries?”

Security Analysis¶

Tool	Description	Example Prompt
`analyze_security_alerts`	Check for security issues	“Check for security problems”

Example Prompts¶

Here are effective prompts to use with Claude Code:

General Analysis¶

"Analyze my application's debug toolbar data"
"What's happening in my app?"
"Show me recent requests and any issues"

Performance¶

"What's the slowest endpoint in my application?"
"Find performance bottlenecks"
"Which requests are taking longer than 200ms?"
"Generate an optimization report for my app"

Security¶

"Are there any security issues in my responses?"
"Check for missing security headers"
"Analyze security alerts from the debug toolbar"

Database¶

"Are there N+1 query problems?"
"How many database queries per request?"
"Find inefficient database access patterns"

Comparison¶

"Compare the performance of /api/users vs /api/posts"
"What changed between these two requests?"

MCP Resources¶

The MCP server also exposes resources for direct data access:

Resource	URI	Description
Request List	`debug://requests`	All tracked requests
Request Details	`debug://request/{id}`	Single request details
Panel Data	`debug://panel/{request_id}/{panel_id}`	Specific panel data
Toolbar Config	`debug://config`	Current configuration
Available Panels	`debug://panels`	List of enabled panels

Programmatic Usage¶

You can also use the MCP server programmatically:

from debug_toolbar import DebugToolbar, DebugToolbarConfig
from debug_toolbar.mcp import create_mcp_server, is_available

if is_available():
    config = DebugToolbarConfig(enabled=True)
    toolbar = DebugToolbar(config)

    mcp = create_mcp_server(
        storage=toolbar.storage,
        toolbar=toolbar,
        redact_sensitive=True,  # Redact passwords, tokens, etc.
        server_name="my-app-debug",
    )

    # Run with stdio transport (for Claude Code)
    mcp.run(transport="stdio")

    # Or SSE transport (for web clients)
    # mcp.run(transport="sse")

Security Considerations¶

Sensitive Data Redaction¶

By default, the MCP server redacts sensitive data like:

Passwords and secrets in headers
Authorization tokens
API keys
Session cookies

Enable/disable with:

mcp = create_mcp_server(
    storage=toolbar.storage,
    toolbar=toolbar,
    redact_sensitive=True,  # Default: True
)

Production Usage¶

The MCP server is intended for development use only. Do not expose it in production environments as it reveals internal application details.

Troubleshooting¶

MCP Server Not Loading¶

Check that mcp package is installed: pip show mcp
Verify settings.json syntax is valid JSON
Restart Claude Code after config changes
Check Claude Code logs for MCP connection errors

No Request Data¶

Ensure your application has the debug toolbar enabled
Make some requests to your application first
Check that max_request_history is > 0 in config

Tools Not Working¶

Verify the MCP server is running: check Claude Code’s MCP status
Try a simple prompt first: “What requests have been made?”
Check that your application is generating debug data

Running the Example¶

Try the included MCP example:

# Terminal 1: Run the web app
make example-mcp

# Terminal 2: The MCP server runs via Claude Code settings

# Then:
# 1. Visit http://localhost:8004 and click around
# 2. Ask Claude Code: "Analyze my debug toolbar data"
